• Electric shift-on-the-fly transfer case -inc: manual-locking front hubs, instrument panel auto rotary control
• 4-wheel drive
• 72 amp/hr (650 CCA) battery
• 157-amp HD alternator
• Trailer tow pkg -inc: 7-wire harness w/relays, 7/4 pin combination connector
• 12.5K trailer hitch receiver -inc: 2" hitch
• Trailer brake controller *Compatible w/select electric over hydraulic brakes*
• 6-3/4' pickup box -inc: (4) tie-down hooks, partitionable & stackable storage
• (2) front tow hooks
• Mono-beam front axle w/coil spring suspension
• HD gas shock absorbers
• Front stabilizer bar
• Pwr steering w/steering damper
• Pwr 4-wheel disc brakes w/vacuum boost
• 2-ton mechanical jack

• (5) LT275/65R18E all-season BSW tires
• 18" 6-spoke bright machined cast aluminum wheels -inc: King Ranch bright hub covers & center ornaments
• Full-size spare tire w/lock & carrier
• Accent color front bumper
• Accent color rear bumper w/step pad
• Front fender vents
• Accent color box top & tailgate moldings
• Accent color bodyside moldings
• Accent color wheel lip moldings
• Painted 6" angular lighted running boards
• Body-color grille w/chrome insert
• Autolamp/rainlamp dual beam halogen headlamps
• Fog lamps
• Pickup box/cargo lights
• Underhood service light
• PowerScope pwr telescoping & folding heated trailer tow mirrors -inc: turn signals, integrated clearance lights, heated convex spotter mirror, memory
• Body-color mirror caps
• Solar tinted glass
• Rear privacy glass
• Pwr sliding rear window
• Interval windshield wipers
• Front/rear license plate brackets
• Body-color door handles
• Removable locking tailgate w/black handle & TailGate Assist
• King Ranch fender badges

• Premium AM/FM stereo w/CD/MP3 player -inc: clock, (8) speakers, subwoofer, aux audio input jack
• SIRIUS satellite radio
• SYNC voice activated communications & entertainment system -inc: Bluetooth® capability, steering wheel audio controls, USB port, audio input jack, 911 Assist, vehicle health reports, turn-by-turn navigation, real-time traffic

• Dual zone electronic automatic temperature control (DEATC)
• Unique King Ranch Chaparral leather 40/console/40 front seats -inc: 10-way pwr heated/cooled driver & passenger seats w/memory, (2) aux pwr outlets in console, easy entry/exit memory feature
• 60/40 flip-up/fold-down rear split bench seat -inc: dual cupholders in armrest, underseat partitioned lockable storage w/aux pwr outlet, (3) head restraints
• Rear armrests w/cupholders
• Color-keyed carpet full-floor covering
• Unique front/rear floor mats w/King Ranch logo
• Color-keyed scuff plates
• Tilt/telescoping steering column
• Unique King Ranch Chaparral leather-wrapped steering wheel w/SYNC controls
• LCD productivity screen -inc: driver configurable enhanced information 4.2" display, menus for gauge setup, trip computer, fuel economy, towing/off-road applications, (5) button message control on steering wheel
• Oil minder system
• Pwr windows w/driver one-touch-down & backlit switches
• Accessory delay
• Pwr door locks w/backlit switches, autolock & auto unlock, SecuriCode keyless entry keypad
• Pwr adjustable pedals w/memory
• Remote keyless entry & perimeter anti-theft alarm
• Remote start system
• SecuriLock anti-theft ignition
• Cruise control
• 3-blink lane change signal
• Universal garage door opener
• (4) air registers w/positive shut-off
• (2) aux pwr outlets in instrument panel
• 110V/150W inverter aux pwr outlet in rear console
• Dash-top tray
• Glove box
• Secondary glove box
• Instrument panel mounted storage bin & trash bag hook
• Instrument panel mounted dual cupholders
• Color-keyed door trim panel -inc: soft armrest, grab handle, reflector, maple woodgrain upper applique, upper & lower map pockets, King Ranch Chaparral leather inserts
• Electrochromic rearview mirror w/compass
• Overhead console -inc: storage bins for garage door opener & sunglasses
• Color-keyed cloth headliner -inc: integrated SYNC microphone
• Front passenger-side roof ride handle
• Rear seating roof ride handles
• Driver & front passenger grab handles
• Dual color-keyed vinyl sunvisors-inc: driver-side map strap, dual covered lighted mirrors
• Front door operated dome lamp w/time delay off & IP switch
• Front/rear map lamps
• Dual color-keyed coat hooks

• 4-wheel anti-lock braking system (ABS)
• AdvanceTrac w/roll stability control (RSC)
• Hill start assist control
• Trailer sway control
• Driver & front passenger airbags
• Driver & front passenger side air bag/curtain
• Reverse vehicle aid sensor
• Rear view camera -inc: electrochromic rear view mirror w/video
• SOS post crash alert system
• Color-keyed safety belts w/front seat outboard height adjustable D-rings
• BeltMinder seatbelt-not-buckled chime & flashing warning light
• Rear door child safety locks
• Child seat tethers on all rear passenger seats
• Tire pressure monitoring system

FX4 OFF ROAD PKG

• hill descent control
• transfer case & fuel tank skid plates
• unique "FX4 Off Road" decal
• Rancho branded colored front/rear shocks

SKID PLATE PKG

• transfer case & fuel tank

KING RANCH

• Pale Adobe lower accent two-tone paint
• accent color wheel lip molding
• accent color box top & tailgate molding
• body-color grille w/chrome insert
• accent color front bumper
• accent color rear bumper w/step pad
• accent color lower bodyside moldings
• King Ranch fender badges
• painted 6" angular lighted running boards
• body-color mirror caps
• PowerScope mirrors w/memory
• King Ranch center cap on wheels
• front/rear floor mats w/King Ranch logo
• unique King Ranch Chaparral leather-wrapped steering wheel w/SYNC controls
• Chaparral Brown leather heated/cooled pwr front seats w/driver memory
• King Ranch Chaparral leather door trim inserts w/woodgrain applique
• pwr adjustable pedals w/memory
• rear view camera
• universal garage door opener
• remote start system

• FX4 Off-Road Package
• King Ranch Package
• 12V power outlets 5 12V power outlets
• 18' Bright Machined 6-Spoke Cast Alum Wheels
• 3-point seatbelt Rear seat center 3-point seatbelt
• 4-Wheel Disc Brakes
• 4WD type Part-time 4WD
• 6' Angular Lighted Painted Running Boards
• 9 Speakers
• ABS brakes
• ABS Brakes 4-wheel antilock (ABS) brakes
• ABS Brakes Four channel ABS brakes
• Accent Color Front Bumper
• Accent Color Rear Bumper w/Step Pad
• Accessory power Retained accessory power
• Adjustable pedals
• Adjustable pedals Power adjustable pedals
• Air Conditioning
• Air conditioning Yes
• All-in-one key All-in-one remote fob and ignition key
• Alloy wheels
• Alternator Type Heavy-duty alternator
• AM/FM radio: SIRIUS
• Amplifier
• Antenna Fixed audio antenna
• Armrests front center Front seat center armrest
• Armrests rear Rear seat center armrest
• Audio storage Audio media storage unit
• Auto door locks Auto-locking doors
• Auto headlights Auto on/off headlight control
• Auto-dimming Rear-View mirror
• Automatic temperature control
• Aux input jack Auxiliary input jack
• Basic warranty 36 month/36,000 miles
• Battery charge warning
• Battery run down protection
• Battery type Dual lead acid batteries
• Beverage holders Front beverage holders
• Beverage holders rear Rear beverage holders
• Block heater Engine block heater
• Body Color Mirror Caps on PowerScope Mirrors
• Body panels Fully galvanized steel body panels with side impact beams
• Bodyside Molding
• Bodyside moldings Body-colored bodyside moldings
• Box style Standard style pickup box
• Brake assist
• Brake assist system
• Brake type 4-wheel disc brakes
• Bumpers front Colored front bumper
• Bumpers rear Colored rear bumper
• Bumpers: chrome
• Cab mounted cargo light
• CD location CD player located in the dashboard/instrument panel
• CD player
• CD Single-disc CD player
• CD-R compatible
• Child door locks Manual rear child safety door locks
• Clearance lights Cab clearance lights
• Climate control Automatic climate control
• Clock Digital clock
• Colored Front & Rear Rancho Branded Shocks
• Compass
• Compressor Intercooled turbo
• Console
• Console insert material Leather console insert
• Convex spotter Driver and passenger convex spotter mirrors
• Cooled front seats Ventilated driver and front passenger seats
• Corrosion perforation warranty 60 month/unlimited
• Cruise control Cruise control with steering wheel mounted controls
• Cylinder head material Aluminum cylinder head
• Day/Night rearview mirror
• Delay off headlights Delay-off headlights
• Delay-off headlights
• Door ajar warning
• Door bins front Driver and passenger door bins
• Door bins rear Rear door bins
• Door handle material Body-colored door handles
• Door locks Power door locks with 2 stage unlocking
• Door mirror style Body-colored door mirrors
• Door mirror type PowerScope power extendable trailer mirrors
• Door mirrors Power door mirrors
• Door panel insert Simulated wood door panel insert
• Door trim insert Leather door trim insert
• Drive type Four-wheel drive
• Driver door bin
• Driver information center
• Driver lumbar Driver seat with 2-way power lumbar
• Driver seat direction Driver seat with 8-way directional controls
• Driver vanity mirror
• Dual front impact airbags
• Dual front side impact airbags
• Dual-zone front climate control
• Electronic Stability Control
• Electronic stability control AdvanceTrac w/Roll Stability Control electronic stability control system with anti-roll
• Emissions tiers Tier 2 Bin 8 emissions
• Emissions ULEV II emissions
• Engine Block Heater
• Engine block material Iron engine block
• Engine compartment light
• Engine Configuration Powerstroke V8
• Engine hour meter
• Engine Location Front mounted engine
• Engine Mounting direction Longitudinal mounted engine
• Engine Powerstroke 6.7L V-8 diesel direct injection, intercooled turbo, diesel, engine with 400HP
• Engine retarder Engine retarder system
• Engine Short Powerstroke 6.7L V-8
• Engine temperature warning
• Engine/electric motor temperature gauge
• External door locks SecuriCode external keypad door lock control
• External memory SYNC external memory control
• Extra Heavy Duty 200-Amp Alternator
• First-row windows Power first-row windows
• Floor console Full floor console
• Floor console storage Locking floor console storage
• Floor coverage Full floor coverage
• Floor covering Full carpet floor covering
• Floor mats Carpet front and rear floor mats
• Fog lights Front fog lights
• Folding door mirrors Power folding door mirrors
• Folding rear seats 60-40 folding rear seats
• Front anti-roll bar
• Front anti-roll Front anti-roll bar
• Front beverage holders
• Front Bucket Seats
• Front Center Armrest
• Front dual zone A/C
• Front fog lights
• Front head restraint control Manual front seat head restraint control
• Front head restraints Height adjustable front seat head restraints
• Front impact airbag driver Driver front impact airbag
• Front impact airbag passenger Passenger front impact airbag
• Front passenger lumbar Front passenger seat with 2-way power lumbar
• Front reading lights
• Front seat upholstery Leather front seat upholstery
• Front seatback upholstery Leatherette front seatback upholstery
• Front side impact airbag driver Seat mounted side impact driver airbag
• Front side impact airbag passenger Seat mounted side impact front passenger airbag
• Fuel Type Diesel
• Fully automatic headlights
• Garage door opener
• Gearshifter material Urethane gear shifter material
• Glove box Standard glove box
• Grille style Colored grille with chrome surround
• Handsfree Bluetooth® handsfree wireless device connectivity
• Headlight type Reflector headlights
• Headlights Halogen headlights
• Headlights on reminder
• Headliner coverage Full headliner coverage
• Headliner material Cloth headliner material
• Heated door mirrors
• Heated door mirrors Heated driver and passenger side door mirrors
• Heated front seats Heated driver and front passenger seats
• Height adjustable seatbelts Front height adjustable seatbelts
• High mount stop light High mounted center stop light
• Hill control Hill descent control
• Hill Descent Control
• Hill start assist
• Ignition Compression ignition system
• Ignition type Mechanical
• Illuminated entry
• Immobilizer SecuriLock immobilizer
• Inclinometer
• Instrumentation display Analog instrumentation display
• Integrated tailgate step
• Interior 120V AC power outlets 1 interior 120V AC power outlet
• Interior accents Chrome and metal-look interior accents
• Interior courtesy lights Fade interior courtesy lights
• Internet access Selective service internet access
• Key in vehicle warning
• Keyfob keyless entry
• Keyfob remote start PowerCode keyfob remote start
• King Ranch Chaparral Lthr-Wrapped Steering Wheel
• Leather steering wheel
• License plate front bracket Front license plate bracket
• Lock-up transmission
• Locking hub control Auto locking hub control
• Low level warnings Low level warning for fuel and brake fluid
• Low tire pressure warning
• Memory Power Adjustable Pedals
• Memory settings Memory settings include: door mirrors and pedals
• Number of airbags 6 airbags
• Number of doors 4 doors
• Number of first-row screens 1 total number of 1st row displays
• Number of memory settings 2 memory settings
• Oil pressure gauge
• Oil pressure warning
• Onboard power supply (kW) 0.150 kW
• One-touch down window Driver one-touch down window
• Order Code 618A
• Outside temperature display
• Overdrive transmission
• Overhead airbag
• Overhead airbags Safety Canopy System curtain first and second-row overhead airbags
• Overhead console
• Overhead console Mini overhead console
• Overhead console storage
• Painted Body Color Grille w/Chrome Insert
• Panic alarm
• Parking sensors Rear parking sensors
• Passenger door bin
• Passenger doors rear left Conventional left rear passenger door
• Passenger doors rear right Conventional right rear passenger door
• Passenger seat direction Front passenger seat with 8-way directional controls
• Passenger vanity mirror
• Perimeter approach lighting Remote activated perimeter approach lighting
• Power door mirrors
• Power driver seat
• Power driver seat controls Driver seat power reclining, lumbar support, cushion tilt, fore/aft control and height adjustable control
• Power Moonroof
• Power passenger seat
• Power passenger seat controls Passenger seat power reclining, lumbar support, cushion tilt, fore/aft control and height adjustable control
• Power steering
• Power windows
• PowerScope Trailer-Tow Mirrors
• Powertrain type ICE
• Powertrain warranty 60 month/60,000 miles
• Premium Leather Seating Surfaces 40/Console/40
• Provisions Snow plow provisions
• Radiator
• Radio AM/FM/SIRIUSsatellite
• Radio data system
• Radio: Navigation System w/HD & Satellite (DISC)
• Radio: Premium AM/FM Stereo w/Single CD/MP3 Player
• RDS Radio data system (RDS)
• Rear bumper step
• Rear camera Rear mounted camera
• Rear cargo door Tailgate
• Rear console climate control ducts
• Rear head restraint control 3 rear seat head restraints
• Rear head restraint control Manual rear seat head restraint control
• Rear head restraints Height adjustable rear seat head restraints
• Rear Parking Sensors
• Rear reading lights
• Rear seat center armrest
• Rear seat direction Front facing rear seat
• Rear seat folding position FlexFold flip forward cushion and rear seatback
• Rear seat upholstery Leather rear seat upholstery
• Rear seatback upholstery Carpet rear seatback upholstery
• Rear seats fixed or removable Fixed rear seats
• Rear seats Split-bench rear seat
• Rear Springs Heavy-duty rear springs
• Rear step bumper
• Rear under seat ducts Rear under seat climate control ducts
• Rear windshield Power rear windshield
• Rear-View Camera
• Rearview mirror Auto-dimming rear view mirror
• Remote keyless entry
• Remote panic alarm
• Remote Start System
• Restricted driving mode/alerts MyKey restricted driving mode/alerts
• Roadside warranty 60 month/60,000 miles
• Roof Clearance Lights
• Satellite Radio
• Seatback storage pockets 2 seatback storage pockets
• Seating capacity 5
• Second-row windows Power second-row windows
• Security system
• Seek scan
• Selectable mode transmission
• Sequential shift control SelectShift Sequential shift control
• Service interval warning Service interval indicator
• Shock absorbers Rancho shock absorbers
• Side steps Illuminated side steps
• Skid plate 2 underbody skid plates
• Snow Plow Prep Package
• Spare tire Full-size spare tire with steel wheel
• Spare tire location Crank-down spare tire
• Speakers number 9 speakers
• Speakers Standard grade speakers
• Special paint Lower accent two-tone paint
• Speed control
• Speed sensitive volume
• Split folding rear seat
• Split front seats Bucket front seats
• Springs front Front coil springs
• Springs rear Rear leaf springs
• Steering Hydraulic power-assist steering system
• Steering mounted audio control Steering wheel mounted audio controls
• Steering mounted climate control Steering wheel mounted climate controls
• Steering type Re-circulating ball steering
• Steering wheel material Leather steering wheel
• Steering wheel mounted audio controls
• Steering wheel telescopic Manual telescopic steering wheel
• Steering wheel tilt Manual tilting steering wheel
• Suspension Firm ride suspension
• Suspension ride type front Mono-beam rigid axle front suspension
• Suspension ride type rear Rigid axle rear suspension
• Suspension type rear Leaf spring rear suspension
• Tachometer
• Tailgate control Manual tailgate/rear door lock
• Tailgate Step & Handle w/TailGate Assist
• Tailpipe Stainless steel single exhaust
• Telescoping steering wheel
• Temperature display Exterior temperature display
• Tilt steering wheel
• Tinted windows Deep tinted windows
• Tires LT275/65SR18 AS BSW 652 RPM front and rear tires
• Tough Bed Spray-In Bedliner
• Tow hooks front 2 front tow hooks
• Towing brake controller Trailer brake controller
• Towing class Class V tow rating
• Towing hitch Trailer hitch
• Towing trailer sway Trailer sway control
• Towing wiring harness Trailer wiring harness
• Traction control
• Traction control All-speed ABS and driveline traction control
• Transfer Case & Fuel Tank Skid Plates
• Transfer case Electronic transfer case shift
• Transmission electronic control
• Transmission oil cooler
• Transmission temperature gauge Transmission fluid temperature gauge
• Transmission TorqShift 6-speed automatic
• Transmission Type Automatic
• Trip computer
• Trip odometer
• Turbo gauge Turbo/supercharger boost gauge
• Turn signal in door mirrors Turn signal indicator in door mirrors
• Turn signal indicator mirrors
• Under seat tray rear Locking rear under seat tray
• Unique Door Trim Panels
• Unique King Ranch Leather 40/Console/40 Front Seats
• Universal Garage Door Opener
• Upfitter switches
• Upfitter Switches (4)
• Variable panel light Variable instrument panel light
• Variably intermittent wipers
• Ventilated brakes Front and rear ventilated disc brakes
• Visor driver mirror Driver visor mirror
• Visor illuminated driver mirror Illuminated driver visor mirror
• Visor illuminated passenger mirror Illuminated passenger visor mirror
• Visor passenger mirror Passenger visor mirror
• Voice activated audio Voice activated audio controls
• Wheel covers Chrome hub wheel covers
• Wheel well trim Colored wheel well trim
• Wheels 20 x 8-inch front and rear silver aluminum wheels
• Window Trim Black side window trim
• Windshield trim Black windshield trim
• Wipers Variable intermittent front windshield wipers
• Wireless streaming Bluetooth® wireless audio streaming

• Electrical
• Cold Cranking Amps @ 0° F (Primary): 650
• Maximum Alternator Capacity (amps): 157
• Maximum Alternator Watts: 2100
• Cooling System
• Total Cooling System Capacity (qts): 21.0
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 4800
• Gross Axle Wt Rating - Rear (lbs): 6290
• Curb Weight - Front (lbs): 3978
• Curb Weight - Rear (lbs): 2967
• Gross Vehicle Weight Rating Cap (lbs): 11000
• Gross Combined Wt Rating (lbs): 19000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 11900
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1785
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 11900
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): 2975
• Suspension
• Suspension Type - Front: Coil Spring
• Suspension Type - Rear: 2-Stage Leaf Spring
• Spring Capacity - Front (lbs): 4800
• Spring Capacity - Rear (lbs): 6290
• Axle Type - Front: Monobeam
• Axle Type - Rear: Full-Floating
• Axle Capacity - Front (lbs): 6000
• Axle Capacity - Rear (lbs): 7280
• Axle Ratio (:1) - Front: 3.73
• Axle Ratio (:1) - Rear: 3.73
• Shock Absorber Diameter - Front (mm): 35.1
• Shock Absorber Diameter - Rear (mm): 35.1
• Stabilizer Bar Diameter - Front (in): 1.10
• Brakes
• Brake Type: Pwr
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 13.7 x 0.5
• Rear Brake Rotor Diam x Thickness (in): 13.4 x 0.3
• Tires
• Front Tire Order Code: TCH
• Rear Tire Order Code: TCH
• Spare Tire Order Code: - TBD -
• Front Tire Size: LT275/65R18E
• Rear Tire Size: LT275/65R18E
• Spare Tire Size: LT275/70R18E
• Front Tire Capacity (lbs): 3415
• Rear Tire Capacity (lbs): 3415
• Spare Tire Capacity (lbs): 3415
• Revolutions/Mile @ 45 mph - Front: - TBD -
• Revolutions/Mile @ 45 mph - Rear: - TBD -
• Revolutions/Mile @ 45 mph - Spare: - TBD -
• Wheels
• Front Wheel Size (in): 18 x 8.0
• Rear Wheel Size (in): 18 x 8.0
• Spare Wheel Size (in): 18 x 8.0
• Front Wheel Material: Aluminum
• Rear Wheel Material: Aluminum
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr
• Steering Ratio (:1), On Center: 20.4
• Steering Ratio (:1), At Lock: 20.4
• Turning Diameter - Curb to Curb (ft): 51.8
• Turning Diameter - Wall to Wall (ft): 53.7
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 26.0
• Fuel Tank Location: Midship
• Exterior Dimensions
• Wheelbase (in): 156.2
• Length, Overall w/o rear bumper (in): 246.8
• Width, Max w/o mirrors (in): 79.9
• Height, Overall (in): 80.8
• Overhang, Front (in): 38.1
• Overhang, Rear w/o bumper (in): 52.4
• Front Bumper to Back of Cab (in): 154.2
• Cab to Axle (in): 39.9
• Cab to End of Frame (in): - TBD -
• Ground to Top of Load Floor (in): 37.8
• Ground to Top of Frame (in): - TBD -
• Frame Width, Rear (in): - TBD -
• Ground Clearance, Front (in): 8.2
• Ground Clearance, Rear (in): 8.2
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 81.8
• Cargo Box Width @ Top, Rear (in): - TBD -
• Cargo Box Width @ Floor (in): - TBD -
• Cargo Box Width @ Wheelhousings (in): 50.9
• Cargo Box (Area) Height (in): 20.0
• Tailgate Width (in): 60.6
• Cargo Volume (ft³): 64.1
• Interior Dimensions
• Passenger Capacity: 4
• Front Head Room (in): 40.7
• Front Leg Room (in): 41.1
• Front Shoulder Room (in): 68.0
• Front Hip Room (in): 67.6
• Second Head Room (in): 40.8
• Second Leg Room (in): 42.1
• Second Shoulder Room (in): 68.1
• Second Hip Room (in): 67.6
• Summary
• Vehicle Name: Ford Super Duty F-350 SRW
• Body Style: Crew Cab 6-3/4'
• Body Code: 156" WB
